International famous brands high-performance DFB lasers are adopted, narrow spectral lines, good linearity, and high output power.
The drive circuit adopts advanced multi-frequency RF predistortion technology and RF power automatic processing technology, which can automatically optimize the drive level so that the C/CTB, C/CSO, and C/N indicators are always at optimal values.
32-bit ARM processor can efficiently coordinate the working status of each module and accurately monitor and control each operating parameter.
Laser temperature stabilization circuit (ATC) and optical power output stabilization circuit (APC) ensure optimal laser performance.
47-862MHz (1000Mhz can be customized) operating bandwidth.
Reserved dual module structure, can increase the function of light emitting, EDFA, light collection, RF switch and other functional modules, can achieve a multi-purpose machine.
Modular structure, easy to extend the function of the equipment and maintenance.
Standard network management interface, in line with SNMP network management protocol.
The dual power supply is hot backup, snap-type fixed, one-touch pull. Easy to operate, firmly fixed. Voltage 220V & 110V & 48V optional.
